VisionPlus

The end-to-end land surveying automation platform.

Automate every step of the surveying process, from field capture to certified deliverable.

AutoCADCivil3DBricscadTotal station SDKs
VisionPlus interface

VisionPlus · Land surveying & civil design suite

The whole survey-to-design workflow, right inside your CAD.

VisionPlus adds COGO, an intelligent parcels manager, building siting, alignments, surfaces and earthwork to AutoCAD, Civil 3D, BricsCAD and MicroStation — so you go from field data to a finished plan without ever leaving your drawing.

VisionPlus utilities running live inside Autodesk Civil 3D 2027
Since 1987
Built by land surveyors, for land surveyors
4 CAD platforms
AutoCAD · Civil 3D · BricsCAD · MicroStation
One database
Points, parcels, surfaces & alignments together
Field → design
Data collector to deliverable in one suite

What you can do

Six workflows your team runs every week — in one add-in

Everything below was captured from VisionPlus running live in Civil 3D. No round-tripping between disconnected tools, no re-keying coordinates.

01 COGO & Field Data

Turn raw field data into clean geometry

Work directly from your data collector. VisionPlus pulls GPS and total-station observations, ASCII, LandXML and its own Vision database into one place, then runs the coordinate geometry you rely on every day.

  • Traverse, polar, offset, intersection & curve tools
  • Import GPS / total-station raw files, ASCII & LandXML
  • Coordinate comparison and field-observation calc workflow
  • Least-squares translation, rotation & scale-factor adjustment

02 Topologic Parcels

A cadastre manager that thinks in parcels

The intelligent, topologic parcels manager builds lots from your survey points or from an existing draft — and keeps areas, bearings, distances and curve tables in sync automatically.

  • Auto-create parcels from points or existing linework
  • Live areas, bearings & distances, and curve (radius) tables
  • Straight and curved boundaries handled in one topology
  • Advanced land-records tools for cadastral deliverables

03 Building Siting

Place buildings with survey-grade precision

The building siting manager lets you drop, move and rotate a footprint inside a parcel while respecting your chosen setbacks and constraints — then documents the placement for setting out.

  • Build the outline plus appendices and interior courtyards
  • Position footprints against parcel constraints and setbacks
  • Automatic translation, rotation and scale-factor solving
  • Full transformation report and building layout / setting-out

04 Alignments

Horizontal alignments from your points

Build alignments straight from picked points or a polyline, then query, extend and report — with LandXML in and out for a clean handoff to design.

  • Create alignments from points or an existing polyline
  • Distance & offset queries; new points by distance / offset
  • Generate left and right right-of-way alignments
  • Import / export LandXML and report along the alignment

05 Surfaces & DTM

Every surface in one project database

Create, edit and triangulate surfaces from points, breaklines, an outline and exclusion holes — then draw them as triangles, contours, grids or sections, all inside one VisionPlus project.

  • Delaunay triangulation or nearest-neighbour grid models
  • Points, outline, breaklines & exclusion holes on tabs
  • See point, breakline & triangle counts per surface
  • Copy, merge, group and move surfaces to solids

06 Earthwork & Volumes

Volumes four ways, with an audit trail

Compute earthwork the way the job demands — surface-to-surface, against a level plane, by cross-sections or from solids — with bulking factors, differential contours and a full report.

  • Four volume methods: surfaces, planes, cross-sections, solids
  • Triangulation or grid, with breakline-aware calculation
  • Apply bulking factors and generate differential contours
  • Delimit the zone and save the resulting intersection surfaces

The full toolbox

Everything in the suite, from first setup to final section

The six workflows above are the highlights. Underneath sits the complete VisionPlus toolset — the same Basic and Advanced training modules your crew would learn, grouped here so you can see the depth at a glance.

Points & field data

Basic
  • Draw, erase, create & edit points
  • Point attributes, fixed points, batch editing
  • Pcodes, control codes (DC) & notes
  • Import GPS & total-station raw files
  • ASCII & LandXML import; coordinate comparison
  • Field observations & calc workflow

COGO & location

Basic
  • Polar computation
  • Area calculation
  • Traverse — direction, angle & report
  • Offset & chainage on a line or alignment
  • Intersection calculations
  • Curve calculations

Strings & drawing

Basic
  • String manipulation & drawing settings
  • Field-coded control codes
  • Lines, text & blocks
  • Dimensions & measurements

Parcels & land records

Basic
  • Intelligent topologic parcels manager
  • Create parcels from points or linework
  • Live areas, bearings, distances & curves
  • Advanced land-records tools

Adjustment & conversion

Advanced
  • Least-squares translation / rotation
  • Traverse adjustment — COMPASS & TRANSIT
  • Mean point, line & curve by least squares
  • Coordinate conversion (e.g. WGS 84 → NAD83 CSRS / MTM)
  • Combined scale factor across drawings

Profiles & sections

Advanced
  • Surface, alignment & raw profile lines
  • Vertical curves, grid & annotations
  • Cross-sections along an alignment
  • Per-section volumes & surface-deviation checks

Why surveyors choose it

Less re-keying. Fewer tools. A cleaner deliverable.

Accuracy you can defend

Least-squares transforms, control-coordinate reports and topologic areas mean the numbers on your plan trace back to the field.

One environment

COGO, cadastre, alignments, surfaces and volumes live in the CAD you already use — not five separate programs.

Clean data exchange

ASCII, LandXML, JXL, DTM and data-collector formats in and out, so field crews and designers stay in sync.

Cadastre-ready

An intelligent, topologic parcels manager builds lots, areas and legal geometry automatically — curves included.

Design-grade surfaces

Triangulate from points and breaklines, then contour, grid and section — with four volume methods for earthwork.

LIDAR-ready

Aerial and mobile LIDAR point clouds sit alongside your survey data in the same VisionPlus project database.

Works where you work

Runs inside the CAD you already own

VisionPlus integrates directly into your standard CAD platform — keep your drawings, layers and standards, and add the survey and civil tools on top.

  • Autodesk AutoCAD
  • Autodesk AutoCAD Map
  • Autodesk Civil 3D
  • Bricsys BricsCAD
  • Bentley MicroStation
  • Bentley PowerDraft

See VisionPlus on your own data

Bring a recent field file and we’ll walk it through COGO, parcels, surfaces and volumes — live, in your CAD. Most surveyors see the time savings in the first ten minutes.

Sales overview prepared from the product-owner walkthrough recorded 07‑07‑2026. Screenshots captured from that session (VisionPlus in Autodesk Civil 3D 2027). For evaluation and demonstration use.

VisionPlus

The 10 best benefits of VisionPlus

From the field to the final plan, VisionPlus automates operations, secures results and speeds up the production of professional deliverables.

01Key benefit

Automate the creation of your plans

Quickly turn your field data into professional drawings with automated creation of points, segments, distances, directions, annotations and parcels.

02Productivity

Save time at every step

Cut manual, repetitive tasks from importing observations all the way to producing the final plan.

03Reliability

Deliver accurate, dependable results

Validate your observations, apply your tolerances and catch errors before they reach your deliverables.

04Control

Centralize all your survey data

Bring field books, coordinates, calculations, parcels, buildings, research, decisions and reports together in one structured environment.

05COGO

Simplify your COGO calculations

Efficiently compute traverses, angles, intersections, areas, curves, offsets and rights-of-way with specialized tools.

06Parcels

Automate parcel management

Create, edit, validate and automatically draw lots or parts of lots from field points or existing projects.

07Quality

Secure your adjustments and transformations

Adjust your observations and transform your coordinates while keeping tighter control over data quality and consistency.

08Standardization

Standardize your working methods

Configure VisionPlus to your organization's standards, drawing settings and procedures for consistent deliverables across every project.

09Traceability

Make search and traceability easy

Quickly find the points, parcels, buildings, observations and project information you need, while keeping the history required for review.

10Integration

Work inside your preferred CAD environment

Use VisionPlus specialized tools directly inside AutoCAD®, BricsCAD®, MicroStation®, PowerDraft® and InCAD ODA, without changing how you work.

VisionPlus automates the surveying process, centralizes data and turns field observations into accurate, consistent, delivery-ready plans faster.
Request a demo
Who it's for

Full-service surveying firms.

Field capture

Total station, GNSS and scanner integration.

Adjustment & QC

Least-squares adjustment with error ellipses.

Automated drafting

Templated plans and certificates.

Choose your edition

VisionPlus

VisionPlus Standard

Core surveying application integrating ODA. InCAD

  • Field capture with total station and GNSS
  • Basic drafting templates and plan output
  • Standard coordinate systems and transformations
  • Email support and knowledge base access
Get a quote for VisionPlus Standard
Most popular
VisionPlus Premium

Full-service automation with adjustment, QC and scanning workflows.

  • Everything in Standard, plus laser scanner integration
  • Least-squares adjustment with error ellipses
  • Advanced drafting templates and certificate generation
  • Priority support and onboarding sessions
Get a quote for VisionPlus Premium
VisionPlus Ultimate

Enterprise deployment with automation, integrations and dedicated support.

  • Everything in Premium, plus multi-user project sharing
  • Custom automation scripts and batch processing
  • Full integration with AutoCAD, Civil3D and Bricscad
  • Dedicated account manager and SLA
Get a quote for VisionPlus Ultimate
Customer story

"CIMA+ cuts its point cloud footprint by 75% with VL365"

From 40 TB of structured scans to 10 TB of unified LAZ on VL365: same accuracy, same density, same immersive 360° views — no more per-scan-position billing and no format lock-in.

Read more customer stories →
Talk to an expert

Request a VisionPlus demo

Tell us about your project, a senior specialist will get back within one business day.

By submitting, you agree to be contacted by Geo-Plus about your inquiry. We never share your data.

Ready to see VisionPlus in action?

Book a live demo tailored to your workflow.
